OMRON - VAQOV151C5 - Pushbutton Switch, VAQ, SPDT
- Switch Operation: -
- Contact Configuration: SPDT
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 250V
- Contact Current Max: 15A
- Switch Terminals: Quick Connect, Solder
- Product Range: VAQ Series
- Colour: Black
- Contact Current @ Contact Voltage AC Max: 15A
- Contact Current AC: 10A
- External Length / Height: 21.9mm
- External Width: 18mm
- Height: 21.9mm
- Illumination Colour: Non-illuminated
- Length: 28mm
- Operating Temperature Max: 80°C
- Operating Temperature Min: -25°C
- Pushbutton Switch Type: Standard
- Thread Size: M10
