description
- Average Forward Current: 160A
- Average On State Current: 160A
- Gate Trigger Current Max: 145mA
- Gate Trigger Voltage Max: 2.5V
- Holding Current Max: 200mA
- No. of Pins: 7Pins
- On State RMS Current: 275A
- Operating Temperature Max: 125°C
- Peak Non Repetitive Surge Current: 5.2kA
- Peak Repetitive Off State Voltage: 1.6kV
- Product Range: -
- Repetitive Peak Reverse Voltage: 1.6kV
- SCR Module Type: Series Connected - SCRs
- Thyristor Case Style: Module
- Thyristor Mounting: Panel
