ENOCEAN - STM 330 - RF Module, Wireless Temperature Sensor, Measurement Range 0°C to 40°C, Resolution 0.16K, 868 Mhz
- RF Modulation: ASK
- Data Rate Max: 125Kbps
- Frequency: 868.3MHz
- Sensitivity dBm: -
- Supply Voltage Min: -
- Supply Voltage Max: -
- Supply Current: -
- RF Transmitter Applications: Wireless Sensor Network
- Product Range: STM330, STM330C
- SVHC: No SVHC (17-Dec-2015)
- Frequency Range: 868.3MHz
- Modulation Type: ASK
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Operating Temperature Range: -20°C to +60°C
