CELDUC - SOM040100 - MOSFET Relay, 60 VDC, 40 A, 0.03 ohm
- Contact Configuration: -
- Load Current: 40A
- Relay Terminals: Screw
- Load Voltage Max: 60VDC
- On State Resistance Max: 0.03ohm
- Isolation Voltage: 2.5kV
- Forward Current If: 35mA
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Control Voltage DC Max: 32V
- Control Voltage DC Min: 3.5V
- Control Voltage Type: DC
- Load Current RMS Max: 40A
- Load Voltage DC Max: 60V
- Load Voltage DC Min: 5VDC
- Output Voltage Max: 60V
- Output Voltage Min: 5V
- Peak Load Voltage +: 100V
- RMS Load Current Min: 5mA
