CELDUC - SO842074 - Solid State Relay, 25 A, 275 Vrms, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 25A
- Operating Voltage Max: 275Vrms
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 12Vrms
- Control Voltage Min: 3VDC
- Control Voltage Max: 32VDC
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
- Control Voltage AC Max: 275VAC
- Control Voltage AC Min: 12VAC
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 3VDC
- Control Voltage Range: 3V DC to 32V DC
- Control Voltage Type: DC
- Isolation Voltage: 4kV
- Load Current Min: 3mA
- Load Current RMS Max: 25A
- Operating Temperature Max: 100°C
- Operating Temperature Min: -55°C
- Operating Voltage Range: 12Vrms to 275Vrms
- Output Type: Voltage
- Output Voltage Max: 275V
- Output Voltage Min: 12V
- Peak Load Voltage +: 600V
- RMS Load Current Min: 5mA
- Surge Current: 350A
