COILCRAFT - SLC7530S-101MLC - Power Inductor (SMD), 100 nH, 40 A, Shielded, 20 A, SLC7530
- Inductance: 100nH
- RMS Current (Irms): 40A
- Inductor Construction: Shielded
- Saturation Current (Isat): 20A
- Product Range: SLC7530 Series
- Power Inductor Case: 7.5mm x 6.7mm x 3mm
- DC Resistance Max: 123µohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 3.75GHz
