description
SEMIKRON - SKR26/12 - Diode Module, 1.2 kV, 25 A, 1.55 V, Single, E8, 2 Pins
- Repetitive Reverse Voltage Vrrm Max: 1.2kV
- Forward Current If(AV): 25A
- Forward Voltage VF Max: 1.55V
- Diode Module Configuration: Single
- Product Range: SKR Series
- SVHC: No SVHC (15-Jun-2015)
- Current Ifsm: 375A
- Diode Case Style: E8
- Diode Configuration: Single
- Diode Polarity: Stud Cathode
- Diode Type: Standard Recovery
- Forward Surge Current Ifsm Max: 375A
- Forward Voltage: 1.55V
- Junction Temperature Tj Max: 180°C
- No. of Phases: Single Phase
- No. of Pins: 2Pins
- Operating Temperature Max: 180°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +180°C
- Thread Size: M6
