CELDUC - SC864110 - Solid State Relay, 50 A, 520 Vrms, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
 - Load Current: 50A
 - Operating Voltage Max: 520Vrms
 - Relay Mounting: Panel
 - Relay Terminals: Screw
 - Switching Mode: Zero Crossing
 - Operating Voltage Min: 24Vrms
 - Control Voltage Min: 5VDC
 - Control Voltage Max: 30VDC
 - Product Range: -
 - SVHC: No SVHC (07-Jul-2017)
 - Contact Voltage AC Max: 1200V
 - Control Voltage AC Max: 520VAC
 - Control Voltage AC Min: 24VAC
 - Control Voltage DC Max: 30VDC
 - Control Voltage DC Min: 5VDC
 - Control Voltage Range: 5V DC to 30V DC
 - Control Voltage Type: DC
 - External Depth: 27mm
 - External Length / Height: 58.2mm
 - External Width: 44.5mm
 - Isolation Voltage: 4kV
 - Load Current Min: 5mA
 - Load Current RMS Max: 50A
 - Operating Temperature Max: 100°C
 - Operating Temperature Min: -40°C
 - Operating Voltage Range: 24Vrms to 520Vrms
 - RMS Load Current Min: 5mA
 - RMS Load Voltage Max: 400V
 - Resistance: 1000ohm
 - Resistance Temperature: 90°C
 - Response Time Off Max: 10ms
 - Response Time On Max: 10ms
 - Surge Current: 550A
