SCHRACK - TE CONNECTIVITY - 1-1393239-9 - General Purpose Relay, Power PCB Relay RT1 Series, Power, Non Latching, SPDT, 230 VAC, 12 A
- Contact Configuration: SPDT
- Coil Voltage: 230VAC
- Contact Current: 12A
- Product Range: RT1 Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 32.5kohm
- SVHC: No SVHC (15-Jan-2019)
- AC Coil Power: 0.74VA
- Approval Bodies: BEAB, CSA, KEMA-KEUR, VDE
- Approval Category: UL Recognised
- Approvals & Standards: CSA, UL, VDE
- Coil Voltage VAC Nom: 230V
- Coil Voltage VDC Nom: 230V
- Contact Current Max: 12A
- Contact Voltage AC Nom: 250V
- Current Rating: 12A
- Dielectric Voltage Coil to Contact: 5000V
- Dielectric Voltage Contact to Contact: 1000V
- External Depth: 12.7mm
- External Height: 15.7mm
- External Length / Height: 15.7mm
- External Width: 29mm
- Lead Spacing: 3.5mm
- No. of Pins: 5Pins
- Nom Operating Power: 0.74VA
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Time: 7ms
- Relay Type: Power
- Release Time: 3ms
- Row Pitch: 7.5mm
