TEXAS INSTRUMENTS - PTN04050CAD - Non Isolated POL DC/DC Converter, 12 W, 5 V, 15 V, 2.4 A, Adjustable
- Output Power Max: 12W
- Output Voltage Min: 5V
- Output Voltage Max: 15V
- Output Current Max: 2.4A
- DC / DC Converter Output Type: Adjustable
- DC / DC Converter Type: DIP
- Input Voltage DC Min: 2.95V
- Input Voltage DC Max: 5.5V
- Height: 9.09mm
- Depth: 22.1mm
- Width: 12.57mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Accuracy %: 2%
- Adjustable Output Voltage Max: 15V
- Adjustable Output Voltage Min: 5V
- Base Number: 4050
- DC / DC Converter Mounting: Through Hole
- Frequency: 525kHz
- Input Voltage Max: 5.5V
- Input Voltage Min: 2.95V
- No. of Outputs: 1Outputs
- No. of Pins: 4Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +85°C
- Output Voltage: 15V
- Power Rating: 12W
- Primary Input Voltage: 5.5V
- Supply Voltage: 5V
- Supply Voltage Max: 5.5V
- Supply Voltage Min: 2.95V
