BLOCK - PT 13/2/9 - PCB Transformer, EI 54 x 18.8, Encapsulated Safety Isolating, 230V, 2 x 9V, 13 VA, 50Hz / 60Hz
- Power Rating: 13VA
- Secondary Voltages: 2 x 9V
- Current Rating: 722mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: PT Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 13VA
- External Depth: 40mm
- External Length / Height: 56mm
- External Width: 47mm
- Hole Spacing - Length: 30mm
- Input Voltage: 230V
- Lead Spacing: 5mm
- Output 2 Voltage Max: 9V
- Output Voltage: 9V
- Pin Diameter: 0.8mm
- Pin Length: 7mm
- Pitch Spacing: 30mm
- Primary Voltages: 1 x 230V
- Secondary Power: 6.5VA
- Single Primary Voltage: 230
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 5kV
- Transformer Type: Encapsulated
- Weight: 420g
