BOURNS - PQ2617BHA-4R7K - Power Inductor (SMD), AEC-Q200, 4.7 µH, 28 A, Shielded, 62.4 A, PQ2617BHA, 27.9mm x 19.8mm x 19mm
- Inductance: 4.7µH
- RMS Current (Irms): 28A
- Inductor Construction: Shielded
- Saturation Current (Isat): 62.4A
- Product Range: PQ2617BHA Series
- Power Inductor Case: 27.9mm x 19.8mm x 19mm
- DC Resistance Max: 0.0025ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
