MEAN WELL - PLC-30-24 - LED Driver, Class II, 30 W, 24 V, 1.25 A, Constant Current, 90 V
- Output Power Max: 30W
- Output Voltage Max: 24V
- Output Current: 1.25A
- LED Driver Mode: Constant Current
- Input Voltage Min: 90V
- Input Voltage Max: 264V
- Product Range: PLC-30 Series
- SVHC: No SVHC (12-Jan-2017)
- Depth: 30mm
- Dimming Control Type: PWM
- Efficiency: 84%
- Height: 30mm
- Length: 160mm
- No. of Channels: 1Channels
- No. of Outputs: 1Outputs
- Operating Temperature Max: 50°C
- Operating Temperature Min: -30°C
- Operating Temperature Range: -30°C to +50°C
- Output Power: 30W
- Output Voltage: 24V
- Power Supply Mounting: Chassis
- Power Supply Output Type: Adjustable, Fixed
- Termination Style: Screw
- Width: 46mm
