KEMET - PEH200SV5100MU2 - Electrolytic Capacitor, Long Life, 10000 µF, 250 V, ± 20%, Screw, 19000 hours @ 85°C
- Capacitance: 10000µF
- Voltage Rating: 250V
- Product Range: PEH200 Series
- Lifetime @ Temperature: 19000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 76.6mm
- Lead Spacing: 32mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 145.5mm
- ESR: 0.014ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 145mm
- Operating Temperature Range: -40°C to +85°C
