LCR COMPONENTS - MR20/420B 20UF/440VAC - Motor Run Capacitor, Metallized PP, Can, 20 µF, ± 10%, Stud Mount - M8, 440 V
- Capacitance: 20µF
 - Product Range: MR/A/440 Series
 - Voltage Rating: 440VAC
 - Capacitor Terminals: Quick Connect, Snap-In
 - Capacitance Tolerance: ± 10%
 - dv/dt Rating: -
 - Capacitor Dielectric Type: PP (Polypropylene)
 - Capacitor Case Style: Can
 - Height: 98mm
 - Diameter: 45mm
 - Stud Size - Metric: M8
 - Operating Temperature Min: -25°C
 - Operating Temperature Max: 85°C
 - Automotive Qualification Standard: -
 - SVHC: No SVHC (15-Jan-2019)
 - Body Diameter: 45mm
 - Capacitance Tolerance ±: ± 10%
 - Capacitor Application: Motor Start / Motor Run
 - Capacitor Mounting: Panel
 - Climatic Category: 40/85/21
 - External Length / Height: 98mm
 - Insulation Resistance: 20000Mohm
 - Lead Length: 6.35mm
 - No. of Pins: 2Pins
 - Operating Temperature Range: -25°C to +85°C
 - Power Factor: 0.001
 - Proof Voltage: 660V
 - Thread Size: M8
 - Tolerance +: 10%
 - Tolerance -: 10%
 - Voltage Rating VAC: 440V
