description
MULTICOMP PRO - MCSD105-101KU - Power Inductor (SMD), 100 µH, 980 mA, Unshielded, MCSD105
- Inductance: 100µH
- RMS Current (Irms): 980mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): -
- Product Range: MCSD105 Series
- Power Inductor Case: 10.2mm x 9mm x 5.4mm
- DC Resistance Max: 0.35ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 9mm
- External Length / Height: 5.4mm
- External Width: 10.2mm
- Lead Spacing: 3.5mm
- No. of Pins: 2Pins
- Resonant Frequency: 100kHz
