VISHAY - IHLP2525CZER4R7M8A - Power Inductor (SMD), 4.7 µH, 5.6 A, Shielded, 5.6 A, IHLP-2525CZ-8A, 6.86mm x 6.47mm x 3mm
- Inductance: 4.7µH
- RMS Current (Irms): 5.6A
- Inductor Construction: Shielded
- Saturation Current (Isat): 5.6A
- Product Range: IHLP-2525CZ-8A Series
- Power Inductor Case: 6.86mm x 6.47mm x 3mm
- DC Resistance Max: 0.0384ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Automotive Qualification Standard: AEC-Q200
