IHLP1616ABERR22M01 Inductor, 0.22UH, 20A, 20% Vishay

VISHAYUGS :IHLP1616ABERR22M01 Code de commande:1741282

Prix:
Prix ​​promotionnel€1,37

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (4330 unité)

description

VISHAY - IHLP1616ABERR22M01 - Power Inductor (SMD), 220 nH, 8.5 A, Shielded, 20 A, IHLP-1616AB-01

  • Inductance: 220nH
  • RMS Current (Irms): 8.5A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 20A
  • Product Range: IHLP-1616AB-01 Series
  • Power Inductor Case: 4.45mm x 4.06mm x 1.2mm
  • DC Resistance Max: 0.012ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (27-Jun-2018)
  • External Depth: 4.06mm
  • External Length / Height: 1.2mm
  • External Width: 4.45mm
  • Inductor Type: High Current
  • No. of Pins: 2Pins
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Resonant Frequency: 100kHz
