OMRON - G2RL-1A-E-CV DC12 - General Purpose Relay, G2RL Series, Power, Non Latching, SPST-NO, 12 VDC, 16 A
- Contact Configuration: SPST-NO
 - Coil Voltage: 12VDC
 - Contact Current: 16A
 - Product Range: G2RL Series
 - Relay Mounting: Through Hole
 - Coil Type: Non Latching
 - Contact Voltage VAC: 250VAC
 - Relay Terminals: Solder
 - Contact Voltage VDC: 24VDC
 - Contact Material: Silver Tin Oxide
 - Coil Resistance: 360ohm
 - Approvals & Standards: CE, UL, VDE
 - Coil Current: 20.8mA
 - Coil Operating Lower Percent Limit: 10%
 - Coil Operating Upper Percent Limit: 70%
 - Coil Voltage VDC Nom: 12V
 - Contact Current AC Max: 16A
 - Contact Current DC Max: 16A
 - Contact Current Max: 16A
 - Contact Voltage AC Max: 440V
 - Contact Voltage AC Nom: 250V
 - Contact Voltage DC Max: 300V
 - Contact Voltage DC Nom: 24V
 - DC Coil Power: 250mW
 - External Depth: 29mm
 - External Height: 15.7mm
 - External Length / Height: 15.7mm
 - External Width: 12.7mm
 - Nom Operating Power: 400mW
 - Operating Temperature Max: 85°C
 - Operating Temperature Min: -40°C
 - Operating Time: 15ms
 - Relay Type: Power
 - Release Time: 5ms
 - Switching Current AC Max: 16A
 - Switching Current DC Max: 16A
