BLOCK - FL6/24 - PCB Transformer, UI 30 x 10.5, Encapsulated Safety Isolating, 2 x 115V, 2 x 24V, 6 VA, 50Hz / 60Hz
- Power Rating: 6VA
- Secondary Voltages: 2 x 24V
- Current Rating: 125mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: FL Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 6VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 22.6mm
- External Length / Height: 53mm
- External Width: 44mm
- Fixing Centres LxW: 47.5x37.5
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 35mm
- Input Voltage: 115V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Length: 22.6mm
- Output 2 Voltage Max: 24V
- Output Voltage: 24V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 10mm
- Primary Voltages: 2 x 115V
- Regulation: 69%
- Secondary Power: 3VA
- Transformer Type: Encapsulated
- Weight: 175g
