WIMA - FKS2D016801A00KSSD - Power Film Capacitor, Film / Foil PET, Radial Box - 2 Pin, 6800 pF, ± 10%, Pulse, Through Hole
- Capacitance: 6800pF
 - Voltage Rating: 100V
 - Capacitor Dielectric Type: PET (Polyester)
 - Capacitance Tolerance: ± 10%
 - Product Range: FKS2 Series
 - Capacitor Case Style: -
 - Capacitor Terminals: Radial Leaded
 - Lead Spacing: 5mm
 - Operating Temperature Min: -55°C
 - Operating Temperature Max: 100°C
 - Automotive Qualification Standard: -
 - SVHC: No SVHC (15-Jan-2019)
 - Capacitance Tolerance ±: ± 10%
 - Capacitor Mounting: Through Hole
 - Climatic Category: 55/100/56
 - External Depth: 6.5mm
 - External Length / Height: 7.2mm
 - External Width: 2.5mm
 - Height: 7.2mm
 - Insulation Resistance: 30000Mohm
 - Lead Diameter: 0.5mm
 - Lead Length: 6mm
 - No. of Pins: 2Pins
 - Operating Temperature Range: -55°C to +100°C
 - Power Factor: 0.007
 - Temperature Coeff. +: 330ppm/°C
 - Temperature Coefficient: +330ppm/°C
 - Tolerance +: 20%
 - Tolerance -: 20%
 - Voltage Rating V DC: 100V
 - Voltage Rating VAC: 63V
