description
WIMA - FKP2O104701G00JSSD - General Purpose Film Capacitor, Film / Foil PP, Radial Box - 2 Pin, 470 pF, ± 5%, 250 V, 1 kV
- Capacitance: 470pF
- Voltage Rating: 1kV
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 5%
- Product Range: FKP2 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 5mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 100°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 5%
- Capacitor Mounting: Through Hole
- External Depth: 5.5mm
- External Length / Height: 7mm
- External Width: 7.2mm
- Height: 7mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +100°C
- Voltage Rating V DC: 1kV
