WIMA - FKP2D002201D00JSSD - General Purpose Film Capacitor, Film / Foil PP, Radial Box - 2 Pin, 220 pF, ± 5%, 63 V, 100 V
- Capacitance: 220pF
- Voltage Rating: 100V
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 5%
- Product Range: FKP2 Series
- Capacitor Case Style: Potted
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 5mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 5%
- Lead Diameter: 0.5mm
- Lead Length: 6mm
- Temperature Coefficient: -200ppm/°C
- Voltage Rating V DC: 100V
