PANASONIC - ECA1CM332 - Electrolytic Capacitor, 3300 µF, 16 V, ± 20%, Radial Leaded, 2000 hours @ 85°C, Polar
- Capacitance: 3300µF
- Voltage Rating: 16V
- Product Range: M Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 12.5mm
- Lead Spacing: 5mm
- Height: 25mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Lifetime @ Temperature: 2000 hours @ 85°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 25mm
- Lead Diameter: 0.6mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Ripple Current AC: 1200mA
