SENSATA/CRYDOM - DR24D06 - Solid State Relay, 6 A, 280 VAC, DIN Rail, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 6A
- Operating Voltage Max: 280VAC
- Relay Mounting: DIN Rail
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24VAC
- Control Voltage Min: 4VDC
- Control Voltage Max: 32VDC
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 32V DC
- Control Voltage Type: DC
- Operating Voltage Range: 24V AC to 280V AC
- Peak Surge Current: 300A
