EATON MOELLER - DILM150(RAC240) - Contactor, DIN Rail, Panel, 690 VAC, 3PST-NO, 3 Pole, 75 kW
- Load Current Inductive: -
 - Relay Mounting: DIN Rail, Panel
 - Operating Voltage: 690VAC
 - Contact Configuration: 3PST-NO
 - No. of Poles: 3 Pole
 - Switching Power AC3: 75kW
 - Switching Current AC1: 180A
 - Coil Voltage VAC Nom: 240V
 - Coil Voltage VDC Nom: -
 - Switching Power AC1: -
 - Load Current Resistive: -
 - Switching Current AC3: 150A
 - Product Range: DILM
 - SVHC: No SVHC (17-Dec-2015)
 - Approval Bodies: CSA, EN, IEC, UL, VDE
 - Coil Voltage: 240V
 - Coil Voltage Max: 240VAC
 - Contact Current: 150A
 - Contact Current AC Max: 150A
 - Contact Voltage AC Max: 400V
 - Contact Voltage VAC: 690V
 - Dielectric Voltage Coil to Contact: 440VAC
 - Dielectric Voltage Contact to Contact: 440VAC
 - External Depth: 176mm
 - External Height: 170mm
 - External Length / Height: 170mm
 - External Width: 90mm
 - Insulation Voltage: 690VAC
 - Main Contact Current AC3 Max: 150A
 - Power Rating: 75kW
 - Relay Terminals: Screw
 - Relay Type: Contactor
