EATON MOELLER - DILA-22(110V50HZ,120V60HZ) - Contactor, 6 A, Panel Mount, 415 V, DPST-NO, DPST-NC, 4 Pole
- Load Current Inductive: 6A
- Relay Mounting: Panel
- Operating Voltage: 415V
- Contact Configuration: DPST-NO, DPST-NC
- No. of Poles: 4 Pole
- Switching Power AC3: -
- Switching Current AC1: 10A
- Coil Voltage VAC Nom: 120V
- Coil Voltage VDC Nom: -
- Switching Power AC1: -
- Load Current Resistive: 10A
- Switching Current AC3: 6A
- Product Range: DILA
- SVHC: No SVHC (17-Dec-2015)
- Approval Bodies: CSA, EN, IEC, UL, VDE
- Coil Type: AC
- Contact Current AC Max: 6A
- Contact Current DC Max: 4A
- Contact Current Max: 6A
- Contact Voltage AC Max: 415V
- Contact Voltage AC Nom: 415V
- Current Rating: 6A
- Dielectric Voltage Coil to Contact: 400VAC
- Dielectric Voltage Contact to Contact: 400VAC
- External Depth: 117mm
- External Length / Height: 68mm
- External Width: 45mm
- Frequency Max: 60Hz
- Frequency Min: 50Hz
- Input Voltage Max: 120VAC
- Input Voltage Min: 110VAC
- Nom Operating Power: 300mW
- Relay Type: Contactor
