ZF ELECTRONICS - DC3C-L1RC - Microswitch, Snap Action, Roller Lever, SPDT, Quick Connect, Solder, 100 mA, 30 VDC
- Microswitch Type: Snap Action
 - Microswitch Actuator: Roller Lever
 - Contact Configuration: SPDT
 - Switch Terminals: Quick Connect, Solder
 - Contact Current Max: 100mA
 - Contact Voltage DC Nom: 30VDC
 - Product Range: DC Series
 - Contact Voltage AC Nom: 250VAC
 - Operating Force Max: 200N
 - SVHC: No SVHC (15-Jan-2019)
 - Actuation Type: Roller Lever
 - Actuator Type: Medium Roller Lever
 - Approval Bodies: ENEC, VDE
 - Approval Category: UL Recognised
 - Contact Current AC: 100mA
 - Contact Current AC Max: 100mA
 - Contact Current DC Max: 100mA
 - Contact Voltage AC Max: 250V
 - Contact Voltage DC Max: 30V
 - Differential Travel Max: 0.6mm
 - External Depth: 6.5mm
 - External Length / Height: 9.25mm
 - External Width: 20mm
 - Fixing Centres LxW: 22.2mm
 - Flammability Rating: UL 94V-O
 - Material: PET/PBT
 - Operating Force: 200N
 - Operating Temperature Max: 120°C
 - Operating Temperature Min: -40°C
 - Over Travel Min: 1.5mm
 - Pre-travel: 5mm
 - Switch Case: PBT (Polybutylene Terephthalate), PET (Polyethylene Terephthalate)
