SENSATA/CRYDOM - CMXE60D10 - MOSFET Relay, CMX Series, DIP, DC Output, SPST-NO (1 Form A), DC, 60 V, 10 A, SIP-4, Through Hole
- Contact Configuration: SPST-NO
- Load Current: 10A
- Relay Terminals: Solder
- Load Voltage Max: 60V
- On State Resistance Max: 0.018ohm
- Isolation Voltage: 2.5kV
- Forward Current If: 12mA
- Product Range: CMXE Series
- SVHC: No SVHC (07-Jul-2017)
- Control Voltage Max: 28VDC
- Control Voltage Min: 20VDC
- Control Voltage Type: DC
- Input Current: 12mA
- Input Voltage: 20V DC to 28V DC
- Load Current Min: 0mA
- Load Voltage Range: 0V DC to 60V DC
- Operating Voltage Max: 60VDC
- Operating Voltage Min: 0VDC
- Output Type: MOSFET
- Relay Mounting: PCB
