BOURNS - CM453232-470KL - Wirewound Inductor, 47 µH, 5 ohm, 10 MHz, 140 mA, 1812 [4532 Metric], CM453232
- Inductance: 47µH
- Product Range: CM453232 Series
- DC Current Rating: 140mA
- High Frequency Inductor Case: 1812 [4532 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 5ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 10MHz
- SVHC: No SVHC (15-Jan-2018)
- Impedance Frequency: 2.52MHz
- Inductor Case Style: 1812 [4532 Metric]
- Operating Temperature Max: 100°C
- Operating Temperature Min: -25°C
