BOURNS - CM453232-331KL - Wirewound Inductor, 330 µH, 14 ohm, 3.5 MHz, 85 mA, 1812 [4532 Metric], CM453232
- Inductance: 330µH
- Product Range: CM453232 Series
- DC Current Rating: 85mA
- High Frequency Inductor Case: 1812 [4532 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 14ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 3.5MHz
- SVHC: No SVHC (15-Jan-2018)
- Impedance Frequency: 0.796MHz
- Inductor Case Style: 1812 [4532 Metric]
- Operating Temperature Max: 100°C
- Operating Temperature Min: -25°C
