SENSATA/CRYDOM - CKM0630 - Solid State Relay, SPST-NO, 30 A, 60 VDC, DIN Rail, Cage Clamp
- Contact Configuration: SPST-NO
- Load Current: 30A
- Operating Voltage Max: 60VDC
- Relay Mounting: DIN Rail
- Relay Terminals: Cage Clamp
- Switching Mode: -
- Operating Voltage Min: 0VDC
- Control Voltage Min: 4VDC
- Control Voltage Max: 32VDC
- Product Range: CKM Series
- SVHC: No SVHC (12-Jan-2017)
- Control Current Min: 9mA
- Control Current Typ: 11mA
- Control Voltage DC Max: 32VDC
- Control Voltage DC Min: 4VDC
- Control Voltage Range: 4V DC to 32V DC
- Control Voltage Type: DC
- External Depth: 99mm
- External Length / Height: 81.9mm
- External Width: 22.5mm
- Insulation Resistance: 1000Mohm
- Leakage Current: 0.1mA
- Load Current Max: 30A
- Load Current Min: 0A
- Load Current RMS Max: 30A
- Load Voltage DC Max: 60V
- Load Voltage DC Min: 0VDC
- Must Actuate Voltage: 4V
- Must Release Voltage: 1V
- Operating Temperature Max: 80°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 0V DC to 60V DC
- Output Type: MOSFET
- Peak Surge Current: 90A
- Surge Current: 90A
- Turn Off Time: 1ms
- Turn On Time: 1ms
