description
NEXPERIA - BSH201,215 - Power MOSFET, P Channel, 60 V, 160 mA, 2.1 ohm, SOT-23, Surface Mount
- Transistor Polarity: P Channel
- Continuous Drain Current Id: -160mA
- Drain Source Voltage Vds: -60V
- On Resistance Rds(on): 2.1ohm
- Rds(on) Test Voltage Vgs: -10V
- Threshold Voltage Vgs: -1.9V
- Power Dissipation Pd: 417mW
- Transistor Case Style: SOT-23
- No. of Pins: 3Pins
- Operating Temperature Max: 150°C
- Product Range: -
- Automotive Qualification Standard: -
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (15-Jan-2018)
- Current Id Max: -300mA
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Termination Type: Surface Mount Device
- Transistor Type: Enhancement
- Voltage Vds Typ: -60V
- Voltage Vgs Max: 20V
- Voltage Vgs Rds on Measurement: -10V
- Voltage Vgs th Max: 1.9V
