EPCOS - B82477G4334M000 - Power Inductor (SMD), 330 µH, 950 mA, Shielded, 1.15 A, B82477G4, 12.8mm x 12.8mm x 8mm
- Inductance: 330µH
- RMS Current (Irms): 950mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.15A
- Product Range: B82477G4 Series
- Power Inductor Case: 12.8mm x 12.8mm x 8mm
- DC Resistance Max: 0.6ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Rating: 950mA
- Inductor Case Style: SMD
- Reel Quantity: 400
