EPCOS - B82477G4223M000 - Power Inductor (SMD), 22 µH, 3.6 A, Shielded, 4.25 A, B82477G4, 12.8mm x 12.8mm x 8mm
- Inductance: 22µH
- RMS Current (Irms): 3.6A
- Inductor Construction: Shielded
- Saturation Current (Isat): 4.25A
- Product Range: B82477G4 Series
- Power Inductor Case: 12.8mm x 12.8mm x 8mm
- DC Resistance Max: 0.038ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Rating: 3.6Arms
- Inductor Case Style: SMD
- Reel Quantity: 400
