EPCOS - B82477G4222M000 - Power Inductor (SMD), 2.2 µH, 8 A, Shielded, 11 A, B82477G4
- Inductance: 2.2µH
- RMS Current (Irms): 8A
- Inductor Construction: Shielded
- Saturation Current (Isat): 11A
- Product Range: B82477G4 Series
- Power Inductor Case: 12.8mm x 12.8mm x 8mm
- DC Resistance Max: 0.01ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Rating: 8A
- Inductor Case Style: SMD
- Reel Quantity: 400
