EPCOS - B82464G4102M000 - Power Inductor (SMD), 1 µH, 7.5 A, Shielded, 10 A, B82464G4, 10.4mm x 10.4mm x 4.8mm
- Inductance: 1µH
- RMS Current (Irms): 7.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 10A
- Product Range: B82464G4 Series
- Power Inductor Case: 10.4mm x 10.4mm x 4.8mm
- DC Resistance Max: 0.007ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Rating: 7.5A
- External Depth: 10.4mm
- External Length / Height: 4.8mm
- External Width: 10.4mm
- Inductance Measurement Frequency: 0.1MHz
- Inductor Case Style: SMD
- Inductor Type: Power Inductor
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Reel Quantity: 750
- Resonant Frequency: 135MHz
- Termination Type: Surface Mount Device
- Tolerance +: 20%
