EPCOS - B82464A4222M000 - Power Inductor (SMD), 2.2 µH, 5.7 A, Unshielded, 8.4 A
- Inductance: 2.2µH
- RMS Current (Irms): 5.7A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 8.4A
- Product Range: -
- DC Resistance Max: 8.4ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- Climatic Category: 55/125/56
- External Depth: 10mm
- External Length / Height: 4.8mm
- External Width: 10mm
- Inductance Measurement Frequency: 0.1MHz
- Inductor Type: Inductor
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Reel Quantity: 750
- Resonant Frequency: 60MHz
- Self Resonant Frequency Min: 60MHz
- Tape Width: 16mm
- Termination Type: Surface Mount Device
