EPCOS - B82464A4154K000 - Power Inductor (SMD), 150 µH, 860 mA, Unshielded, 1 A, B82464A4
- Inductance: 150µH
- RMS Current (Irms): 860mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 1A
- Product Range: B82464A4 Series
- Power Inductor Case: 10.4mm x 10.4mm x 4.8mm
- DC Resistance Max: 0.4ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- DC Current Rating: 860mA
- Inductor Case Style: SMD
- Reel Quantity: 750
