EPCOS - B82462A4332M000 - Power Inductor (SMD), 3.3 µH, 2 A, Unshielded, 3.2 A
- Inductance: 3.3µH
- RMS Current (Irms): 2A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 3.2A
- Product Range: -
- Power Inductor Case: 6mm x 6mm x 3mm
- DC Resistance Max: 0.06ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- Attenuation Frequency Range: 100 kHz
- Climatic Category: 55/125/56
- External Depth: 6mm
- External Length / Height: 3mm
- External Width: 6mm
- Inductance Measurement Frequency: 0.1MHz
- Inductor Type: Inductor
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Reel Quantity: 2500
- Resonant Frequency: 60MHz
- Tape Width: 12mm
- Termination Type: Surface Mount Device
