EPCOS - B82422T1102K000 - Wirewound Inductor, 1 µH, 0.6 ohm, 300 MHz, 400 mA, 1210 [3225 Metric], B82422T
- Inductance: 1µH
- Product Range: -
- DC Current Rating: 400mA
- High Frequency Inductor Case: 1210 [3225 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 0.6ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 300MHz
- SVHC: No SVHC (07-Jul-2017)
- Core Material: Ferrite
- Inductor Case Style: 1210 [3225 Metric]
- Q Factor: 30
- Q Test Frequency: 7.96MHz
- Reel Quantity: 2000
