EPCOS - B82422H1334K000 - Wirewound Inductor, 330 µH, 13 ohm, 4.5 MHz, 90 mA, 1210 [3225 Metric], B82422H
- Inductance: 330µH
- Product Range: B82422H Series
- DC Current Rating: 90mA
- High Frequency Inductor Case: 1210 [3225 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 13ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 4.5MHz
- SVHC: No SVHC (27-Jun-2018)
- Core Material: Ferrite
- Inductor Case Style: 1210 [3225 Metric]
- Q Factor: 20
- Q Test Frequency: 796kHz
- Reel Quantity: 2000
