KEMET - A750KK108M0JAAE015 - Polymer Aluminium Electrolytic Capacitor, 1000 µF, 6.3 V, Radial Leaded, 0.015 ohm
- Capacitance: 1000µF
- Voltage Rating: 6.3V
- AE Capacitor Case: Radial Leaded
- Product Range: A750 Series
- ESR: 0.015ohm
- Lifetime @ Temperature: 2000 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 8mm
- Height: 8mm
- Lead Spacing: 3.5mm
- Leakage Current: 1.26mA
- Ripple Current AC: 4.1A
