GRAYHILL - 78RB05ST - DIP / SIP Switch, 5 Circuits, Slide, Through Hole, SPST, 24 VDC, 150 mA
- No. of Circuits: 5Circuits
- Switch Actuator Style: Slide
- Switch Mounting: Through Hole
- Contact Configuration: SPST
- Contact Voltage DC Max: 24VDC
- Contact Current DC Max: 150mA
- Product Range: 78 Series
- Switch Type: DIP Sealed
- SVHC: No SVHC (27-Jun-2018)
- Actuation Type: Flat
- Actuator Type: Recessed Slide
- Capacitance: 2pF
- Contact Resistance: 30mohm
- Dielectric Strength VDC: 500V
- External Depth: 9.65mm
- External Length / Height: 7.49mm
- External Width: 14.7mm
- Insulation Resistance: 1000Mohm
- Lead Spacing: 2.5mm
- No. of Electrical Operations: 2000
- No. of Mechanical Operations: 2000
- No. of Positions: 5Ways
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Pitch Spacing: 2.54mm
- Row Pitch: 7.62mm
- Storage Temperature Max: 85°C
- Storage Temperature Min: -55°C
