MURATA POWER SOLUTIONS - 78604/2C - Pulse Transformer, PCB, 2:1, 500 µH, 0.34 ohm, 10 Vµs, 1 kV, 78604/2C Series
- TRANSFORMER, PULSE, 2: 1, 500UH
- Turns Ratio: 2
- Isolation Voltage: 1kV
- Product Range: 786 Series
- Inductance: 500µH
- DC Resistance: 0.34ohm
- ET Constant: 10Vµs
- SVHC: No SVHC (07-Jul-2017)
- Capacitance: 13pF
- External Depth: 6.35mm
- External Length / Height: 9.52mm
- External Width: 8.89mm
- Flammability Rating: UL94V-0
- Leakage Inductance: 0.65µH
- Operating Temperature Max: 70°C
- Operating Temperature Min: 0°C
- Primary Inductance: 500µH
- Secondary Resistance: 0.34ohm
- Transformer Type: Pulse
- Winding Configuration: 2
- Winding Resistance Max: 0.34ohm
