WURTH ELEKTRONIK - 74455215 - Power Inductor (SMD), 150 µH, 250 mA, Unshielded, 270 mA, WE-PD4, 6.6mm x 4.45mm x 2.92mm
- Inductance: 150µH
- RMS Current (Irms): 250mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 270mA
- Product Range: WE-PD4 Series
- Power Inductor Case: 6.6mm x 4.45mm x 2.92mm
- DC Resistance Max: 2ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Inductor Type: Power
- No. of Pins: 2Pins
- Resonant Frequency: 6MHz
- Self Resonant Frequency Min: 6MHz
