description
WURTH ELEKTRONIK - 7445430 - Power Inductor (SMD), 1 mH, 220 mA, Shielded, 350 mA, WE-PD3, 12.7mm x 10mm x 4.9mm
- Inductance: 1mH
- RMS Current (Irms): 220mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 350mA
- Product Range: WE-PD3 Series
- Power Inductor Case: 12.7mm x 10mm x 4.9mm
- DC Resistance Max: 3.2ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Inductor Type: Power
- No. of Pins: 2Pins
- Resonant Frequency: 1.9MHz
- Self Resonant Frequency Min: 1.9MHz
