WURTH ELEKTRONIK - 744393440033 - Power Inductor (SMD), 330 nH, 16.5 A, Shielded, 31 A, WE-XHMI, 6.65mm x 6.45mm x 2.4mm
- Inductance: 330nH
- RMS Current (Irms): 16.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 31A
- Product Range: XHMI Series
- Power Inductor Case: 6.65mm x 6.45mm x 2.4mm
- DC Resistance Max: 0.0021ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
