description
WURTH ELEKTRONIK - 744071680 - Power Inductor (SMD), 68 µH, 1.3 A, Shielded, 1.1 A, WE-TPC
- Inductance: 68µH
- RMS Current (Irms): 1.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.1A
- Product Range: WE-TPC Series
- Power Inductor Case: 8mm x 8mm x 4.3mm
- DC Resistance Max: 0.23ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Resonant Frequency: 8MHz
- Self Resonant Frequency Min: 8MHz
