744071470 Power Choke, 47UH, 1.6a, 10MHz Wurth Elektronik

WURTH ELEKTRONIKUGS :744071470 Code de commande:2114332

Prix:
Prix ​​promotionnel€3,77

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (64 unité)

Documents et téléchargements

description

WURTH ELEKTRONIK - 744071470 - Power Inductor (SMD), 47 µH, 1.6 A, Shielded, 1.3 A, WE-TPC

  • Inductance: 47µH
  • RMS Current (Irms): 1.6A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 1.3A
  • Product Range: WE-TPC Series
  • Power Inductor Case: 8mm x 8mm x 4.3mm
  • DC Resistance Max: 0.15ohm
  • Inductance Tolerance: ± 30%
  • SVHC: No SVHC (15-Jan-2019)
  • Resonant Frequency: 10MHz
  • Self Resonant Frequency Min: 10MHz
